P3.91 SMD Outdoor Rental LED Display Panels
P3.91 SMD outdoor rental LED display panels not only can produce extremely clear image details at very close viewing distance but can also present flicker free effects for professional camera shoooting. It is a high end rental solution for all kinds of indoor and outdoor events.
Features:
- Utra-high definition, 65,536 pixels per SQM;
- Superb white balance and wide view angles;
- High brightness and contrast ratio;
- IP65 rating, perfect for indoor & outdoor uses;
- Die-casting aluminum material, excellent heat dissipation;
- Exquisite appearance and seamless connection;
- Light weight, only 9KG, easy set up and tear down;
- The modules can be quickly dismantled for servicing.
Specifications:
| 1 |
Pixel pitch |
3.91mm |
| 2 |
Pixel density |
65,536 pixels/sq.m |
| 3 |
Pixel configuration |
1R1G1B, SMD2525 3in1 |
| 4 |
LED module size (L*H) |
250*250mm |
| 5 |
LED module resolution |
64*64 pixels |
| 6 |
LED panel size (L*H*D) |
500*500*80mm or 500*1000*80mm |
| 7 |
led panel resolution |
128*128 pixels |
| 8 |
LED display panel weight |
8.5KG/piece |
| 9 |
LED display panel material |
Diecasting aluminum |
| 10 |
Brightness |
≥5,000 nits/sq.m |
| 11 |
Driving method |
1/13 scan |
| 12 |
Viewing angle |
140°H /140°V |
| 13 |
Best viewing distance |
3.9M |
| 14 |
Refresh rate |
≥1,200Hz |
| 15 |
Grey scale |
≥8,196 levels |
| 16 |
Display colors |
>16.7M |
| 17 |
Power consumption |
Max.:980W/sq.m, Avg.:392W/sq.m |
| 18 |
Input voltage |
110~230V/AC (±10%) |
| 19 |
Input power frequency |
50/ 60Hz |
| 20 |
IP rating (front/rear) |
IP65/54 |
| 21 |
Operating environment |
Temperature: -20°C~+50°C, Humidity: 10%~95% |
| 22 |
Storage environment |
Temperature:-40-50°C, Humidity: 10-90% |
| 23 |
Life span (50% brightness) |
≥100,000 hours |
| 24 |
Control system |
LINSN or other popular control systems |
| 25 |
Transmission distance |
Multi mode fiber <500m, single mode fiber <30Km, internet cable <100m |
| 26 |
Operating system |
Windows XP/Win7//8/Vista |
| 27 |
Video input/with video processor: Rgblink,Vdwall,Magnimage,etc |
VGA,DVI,DHMI,SDI,RGB,CVBS,HD-SDI,etc |
| 28 |
Compliant standard |
CE/UL/RoHS |
