  • Indoor P6 SMD Full Color LED Video Screen
  • Indoor P6 SMD Full Color LED Video Screen
Indoor P6 SMD Full Color LED Video ScreenIndoor P6 SMD Full Color LED Video Screen

Indoor P6 SMD Full Color LED Video Screen

  • Indoor LED Display
  • Model: LLP-IFP6MM
  • Pixels: 27,777 dots/sq.m
  • Controller: LINSN or others
  • Product description: Indoor P6 SMD full color LED video screen integrated with SMD 3in1 technology, is one of the most widely used models for indoor fixed application requiring high video clarity at close viewing distance

Indoor P6 SMD Full Color LED Video Screen

- Cost effective and less maintenance;
- Easy to install and dismantle;
- Support all kinds of high refresh rate driver ICs;
- Calibration technology on the LED lamps is supported;
- Widely used for both fixed and rental installations;
- Double sides, curve shape can be customized;
- With fiber optic cable to avoid signal delay for long distance transmission;
- Support LINSN and other popular LED controller sysetms;
- User friendly software operation, all programs can be digitally edited;
-High compatibility with all kinds of video formats on its playing software.


1 Pixel pitch
2 Pixel density
27,777 pixels/sq.m
3 Pixel configuration
1R1G1B, SMD3525 or SMD2121, 3-in-1
4 LED module size (L*H)
5 LED module resolution
32*16 pixels
6 LED panel size (L*H*D)
768*576*80mm or as requested
7 LED panel resolution
128*96 pixels
8 LED video screen panel weight
12KG/piece with aluminium alloy
9 LED screen panel material
Diecasting aluminum/aluminium alloy/iron at customer's request
10 Brightness
≥1,600 nits/sq.m
11 Driving method
1/8 scan
12 Viewing angle
140°H /140°V
13 Best viewing distance
14 Refresh rate
15 Grey scale
≥4,096 levels
16 Display colors
17 Power consumption
Max.:1,200W/sq.m, Avg.:480W/sq.m
18 Input voltage
110~230V/AC (±10%)
19 Input power frequency
50/ 60Hz
20 IP rating (front/rear)
21 Operating environment
Temperature: -20°C~+50°C, Humidity: 10%~95%
22 Storage environment
Temperature:-40-50°C, Humidity: 10-90%
23 Life span (50% brightness)
≥100,000 hours
24 Control system
LINSN or other popular control systems
25 Transmission distance
Multi mode fiber <500m, single mode fiber <30Km, internet cable <100m
26 Operating system
Windows XP/Win7//8/Vista

Video input/with video processor:


28 Compliant standard
